Included in Kit:
24.5" Flanders Scientific AM250 OLED Reference Monitor
Sunhood
Light Stand Adapter
50' SDI Cable
50' HDMI Cable
HDMI - SDI converter
DVI - HDMI adapter
Rolling Case

Overview
In addition to the CFE capabilities, the 24.5" Flanders Scientific AM250 OLED Reference Monitor comes equipped with instantly selectable gamma, peak luminance, and color temperature presets, which add to the flexibility of this unit and make it suitable for a wide variety of applications and environments.

The AM250 comes pre-calibrated from the factory and free recalibration is always available for customers that would like to send their units in to one of FSI’s service departments. In addition to this free recalibration option the AM250 also features a wide variety of manual calibration toggles, interfaces with FSI’s Direct Connect Automatic Alignment System, and is also compatible with advanced color management systems like LightIllusion’s LightSpace CMS or SpectralCal’s CalMan allowing you to choose the color management option that works best for you.

This unit features many broadcast monitor basics like a Blue Only Mode, Monochrome Mode, Markers, Safety Areas, H/V Delay, and Tally Lights. The AM250 also comes standard with advanced features like 16 Selectable Scopes, Focus Assist, Time Code Display, Audio Disembedding, Artifact Free Pixel Zoom, Adjustable Exposure Check, On-screen Alarms, and Advanced Pixel Level Measurement.

The AM250 comes with standard DC (24V) and AC (100~240 VAC) power connectors. Every AM250 comes standard with a basic desktop stand and can also be integrated with a wide variety of alternate stands and mounts, like their popular VESA to C-Stand Mount, using the 100mm VESA mounting points. The lightweight and extremely durable aluminum frame allows for easy mounting in any environment while providing long term durability.

Up to two types of Scopes can be displayed simultaneously and can be toggled on/off instantly with a single button press. Scope Windows can be displayed in any of 6 onscreen locations and the two scope windows can be stacked on top of each other or sit side by side for maximum flexibility. FSI is also one of the few companies to provide this scope functionality across all inputs, even DVI.

Panel Specifications:

Screen Size: 24.5"
Resolution: 1920x1080
Bit Depth (Color): 10 bit OLED (1.073 Billion Colors)
Contrast Ratio: ≥ 5000:1
Backlight: N/A
Pixel Efficiency: 99.99%
Max Luminance: >300nits / L40
Viewing Angle: 178°

Inputs:

1 x DVI-I (Analog/Digital)
2 x BNC 3Gbps/HD/SD-SDI
1 x BNC Composite
3 x BNC Component (YPbPr/RGB)

Outputs:

2 x BNC 3Gbps/HD/SD-SDI
1 x BNC Composite
3 x BNC Component (YPbPr/RGB)

Supported SDI Formats:

ITU-R BT.656 (PAL): 576i (50)
SMPTE-125M: 480i (59.94)
SMPTE-274M
1080i (60/59.94/50)
1080p (30/29.97/25/24/24PsF/23.98/23.98PsF)
SMPTE-296M: 720p (60/59.94/50/30/29/25/24/23.98)
2K: 2048x1080 (30p/30PsF/29.97p/29.97PsF/25p/25PsF/24p/24PsF/23.98p/23.98PsF)
SMPTE-425M-AB: 12 & 10 bit 4:2:2 1920x1080p (60/59.94/50)
Level A & Level B supported: 4:4:4 1280x720p (60/59.94/50/30/29.97/25/24/23.98)
Level B supports 2 x SMPTE: 12 & 10 bit 4:4:4 1920x1080i (60/59.94/50)
292M image format mapping: 12 & 10 bit 4:4:4 1920x1080p (30/29.97/25/24/24PsF/23.98/23.98PsF)
372M image format mapping: 12 & 10 bit 2k (2048x1080)
RGB, YCbCr, & XYZ supported: (30p/30PsF/29.97p/29.97PsF/25p/25PsF/24p/24PsF/23.98p/23.98PsF)
*XYZ mapped to Selected Color Gamut on Display Alignment Menu

Supported DVI-I Formats:

DVI-Analog & DVI-Digital: VGA (640x480), NTSC (720x480), SVGA (800x600), XGA (1024x768), SXGA (1280x1024)
DVI Digital Only: 1280x720, 1440x900, 1920x1080, 1920x1200

Audio:

Audio Disembedding: Yes
Audio Level Meters: Yes
Internal Speakers: 2
Audio In (Mini-Jack): 1
Audio Out (Mini-Jack): 1

Features:

Rack Mount Kit: Optional
Desktop Stand: Standard
External Mounting Points: 100mm VESA
VESA to Light Stand Mount: Optional
Carrying Bag with Integrated Hood: N/A
Clear Protective Cover: Optional
16 Mode Scopes: Yes
Measurement Function: Yes
Timecode Display (SD/HD-SDI): LTC, VITC 1, VITC 2
Color Fidelity Engine: Yes
1:1 Pixel Mapping: Yes
Blue Only & Mono Mode: Yes
Side by Side Monitoring: No
3D LUT Color Space Selection: SMPTE C/EBU/REC709/DCI-P3
Color Temperature Select: 3200K, 5000K, 5600K, 6500K, 9300K
Gamma Selection: 1.0 / 1.8 / 2.0 / 2.2 / 2.35 / 2.4 / 2.6 / 2.8

Power:

AC Input: IEC / C14
DC Input: 4 PIN XLR
Battery Plate: Optional
Power Requirement: 100~240 VAC / 12~24 VDC
DC Power Consumption (Appx.): 50 Watts

Physical Characteristics:

Weight (without stand): 17.0 lbs (7.7 kg)
Weight with Basic Desktop Stand: 19.2 lbs (8.7 kg)
Chassis: Aluminum Frame
